商品描述
SY-125自動裝盒機(瓶裝型)
功能特點:
本該設備主要用于軟膏類藥瓶(鋁瓶及塑料瓶)的自動裝盒機。該機自動完成說明的折疊，紙盒成型自動打開形成軟膏藥瓶的自動裝盒，三者同事統一完成動作的功能，并能在盒端自動打印批號。變頻調速，采用PLC自動控制、人機8界面操作系統，自動顯示裝盒速度及計數。
規定范圍內可實現多規格裝盒且不需要更換零配件。設備還設有自動檢測系統，并對不合格的產品采用定位停機并自動剔除的功能，顯示屏上設有故障顯示及排除方法。
用途:
本機廣泛用于制藥、食品、日化等眾多領域的包裝。如：制藥的固體制劑(片劑、膠囊劑等)產品的泡罩裝盒，膏狀、乳脂、膠體產品軟膏的裝盒，用于西林瓶、安培瓶、注射器的托盤式的裝盒，用于液體、固體藥品的瓶式裝盒；用于粉末和顆粒產品的袋式裝盒等。食品類的各種形式的袋式裝盒各種灌裝、盒裝的裝盒，甜品、巧克力、糖果、餅干、瓶式酒類、冷凍制品的裝盒等。日化類的膏狀、乳脂、洗液膠體產品軟管或袋裝式、瓶狀的裝盒，牙膏、肥皂制品的裝盒電燈泡、計算機軟盤、膠帶卷、攝影膠卷等各形式裝盒。
Functional Features：
This machine is continuous motion standing cartoning machine. It is high technology integrative product, which can fully meet requirement of GMP, SY-125 is composed of products conveying belt, box feeding and releasing system, encoder system and box packing machine.Max speed is up to 100 boxes per minute. According to different production equipment, we designed feeding system combined with this machine, which contributes to high efficiency and economical management for our clients. The main advantage is easy and convenient for specification interchange, so it will be more suitable for variable specification.
Product Application:
It is widely used for different packing including drug, food, commodity and cosmetic. For drug industry such as: cover box for solid torch and capsule, soft box for liquid paste, grease and colloid, tray box for vial, ampule bottle, and injector, as well as bottle box for solid and liquid drug and bag box for powder and grain products For food field such as: carton for cans, sweet, chocolate, candy, biscuit, wine, and freezing food,and so on. For commodity and cosmetic industry such as: carton for cream, grease, lotion, colloid, toothpaste, soap, lamp, computer floppy disk.
主要技術參數：Main Technical Parameters:
機器型號Machine model | SY-125 |
外形尺寸Machine dimension(mm) | 1300(L)×1200(W)×1500(H) |
包裝尺寸packaging dimension(mm) | (L)49-100×(W)30-80×(H)28-55 |
包裝速度packaging speed | 40-100瓶（bottles) /分 |
用氣量air consumption | 5-8L / Min |
總功率total power | 1.5kw |
電壓voltage | 220V/380V/50Hz |
整機重量（約）weight(about) | 950kg |
